Hoses and hose lines

Fasteners with application-specific fittings

Hoses made of rubber, plastic and metal compounds offer universal application possibilities in all areas of industry. They are used for conveying and transporting liquid, granular and gaseous media or for suction and pressure transmission. Protective hoses are also used to shield cables or other sensitive lines from external influences. The requirements placed on the JÄGER Group’s hoses and hose lines are correspondingly extensive. They should be flexible, elastic and abrasion-resistant, but must also be pressure and vacuum-resistant as well as mechanically, thermally and chemically resilient.
Gummi Schlaeuche

Quickfacts hoses & hose lines

Application

Flexible connection, transport of media, protection against environmental influences / media leaks

Materials

Rubber: NR, CR, SBR, silicone, NBR, FKM, EPDM Plastic: PC, PUR, PE, PTFE

Length

Individually customizable

Quantity

as of 1 piece

Manufacture

Extrusion, winding process, braiding process, cord process, etc.

Dimensions

from 0,5 mm

Fittings

z. e.g. male threaded nipple, sealing cone with union nut, pipe socket

Color

Plastic: can be colored as desired, rubber: on request
ApplicationFlexible connection, transport of media, protection against environmental influences / media leaks
MaterialsRubber: NR, CR, SBR, silicone, NBR, FKM, EPDM Plastic: PC, PUR, PE, PTFE, PVC, PA
LengthIndividually customizable
Quantityas of 1 piece
ManufactureExtrusion, co-extrusion, long length, winding process, etc.
Dimensionsfrom 0,5 mm
Fittingsz. e.g. male threaded nipple, sealing cone with union nut, pipe socket
ColorPlastic: can be colored as desired, rubber: on request

Request a free sample now

Receive your preferred product sample free of charge by filling out our request form. Our team will be happy to assist you!
Free sample

Rechter Bereich

Checkboxen *

* = Pflichtfeld

Further details in the catalog

Discover more information in our extensive product catalog.

Request a free sample now

Receive your preferred product sample free of charge by filling out our request form. Our team will be happy to assist you!
Free sample

Rechter Bereich

Checkboxen *

* = Pflichtfeld

Application areas

We offer a comprehensive range of hoses for various applications: for pressure or vacuum loads, in various wall thicknesses and lengths as well as with and without fittings. This diversity enables reliable use in agriculture and the food industry (e.g. dairies) as well as in gravel works, mechanical engineering and pipeline construction.

We offer among other things:

Details of the hose technology

Soul

The core is the inner layer of the hose that primarily comes into contact with the pumped medium. In addition to chemical and thermal resistance, the physical stress caused by abrasion, pressure and temperature is also decisive for the safety and service life of the hose.

Spiral

With spiral hoses, a spiral helix is installed between the core and cover to stabilize the hose against the change in cross-section in the event of a vacuum and to increase the kink resistance. To simplify fitting installation, spiral hoses can be designed with spiral-free ends.

Cover

As the modulus of elasticity of rubber and plastic is comparatively low, hoses are fitted with inserts to reinforce them if they are to be subjected to higher operating pressures. The different selection and number of inserts are determined almost exclusively by the required pressure rating.

Insert

The sensitive strength members and inserts are protected from external influences by the hose cover. The right choice of material determines the resistance to abrasion, media attack and weathering and is therefore decisive for the service life.

Guidelines and standards

Test methods
